PX Series Eccentric Pulper

PX Series Eccentric Pulper

PX Series Eccentric Pulper is mainly used to pulp all kinds of waste paper, virgin pulp board and paper machine broken paper.

We’re here to help:

Easy ways to get the answers you need.

Service Online

+86-371-55129198, +86-13783579051

leizhanmachine@gmail.com

+86-371-86138029

+86-371-55129198, +86-13783579051

leizhanmachine@gmail.com

+86-371-86138029

PX Series Eccentric Pulper

Features

- 1. Rotor and sieve plate with eccentrically design, double cone structure.
- 2. Lower energy consumption, 20% energy saving than traditional pulper.
- 3. The twisted rope of the Ragger has a wider movement area, the twisted rope is far away from the rotor, the rotor load is smaller, and the risk of twisted rope breakage is reduced.

Technical Data

PX-V Eccentric Pulper
Model	PX15-V	PX20-V	PX25-V	PX30-V	PX35-V	PX40-V	PX50-V	PX65-V	PX85-V	PX107-V
Nominal Volume(m³)	15	20	25	30	35	40	50	65	85	107
Treatment Consistency(%)	4-8
Capacity(t/d)	60-90	80-120	120-170	140-190	10-230	220-290	300-400	400-550	600-700	800-1000
Motor Power(KW)	110	132	160	220	250	280	355	500	630	800

PX-R Eccentric Pulper
Model	PX20-R	PX25-R	PX30-R	PX35-R	PX40-R	PX52-R	PX73-R	PX95-R	PX120-R	PX175-R
Nominal Volume(m³)	20	25	30	35	40	50	65	85	120	175
Treatment Consistency(%)	4-8
Capacity(t/d)	140-180	180-230	230-280	270-320	300-370	400-450	550-600	650-750	800-1000	1300-1500
Motor Power(KW)	160	185	250	280	315	400	560	710	900	1300
